SJ-740 |
SJ-540 |
SC-540 |
| 噴墨 / 切割方式 |
噴墨: 微壓電式 |
噴墨: 微壓電式
切割: 材質移動方式 |
| 噴墨 / 切割寬度 |
210 to 1869 mm (8-5/16
to 73-9/16 in.) |
210 to 1361 mm (8-5/16
to 53-9/16 in.) |
185 to 1346 mm (7-5/16
to 53 in.) |
| 可接受材質寬度 |
210 to 1879 mm (8-5/16
to 74 in.) |
210 to 1371 mm (8-5/16
to 54 in.) |
210 to 1371 mm (8-5/16
to 54 in.) |
| 使用材質的條件 |
材質最大厚度: 1.0
mm (0.039 in.)
整捲紙的最大直徑: 180 mm (7-1/16 in.)
紙捲的內徑:50.8 mm (2 in.) or 76.2 mm (3 in.)
可使用材質最大重量: 20 kg (44.1 lb.) |
可切割材質最大厚度: 0.08 to 0.22
mm (0.00315 to 0.00866 in.)
(依材質特性而定)
可切割材質最大厚度(包括離型紙): 0.4 mm (0.0157 in.)
材質最大厚度:1.0 mm (0.039 in.)
整捲紙的最大直徑: 180 mm (7-1/16 in.)
紙捲的內徑:media: 50.8 mm (2 in.) or 76.2 mm (3 in.)
可使用材質最大重量: 20 kg (44.1 lb.) |
| 墨水 |
種類 |
Exclusive
SOL INK cartridges |
| 容量 |
220 cc ± 5
cc |
| 顏色 |
C、M、Y、K、Lc、Lm 六色 |
| 列印解析度 |
Max 1440 dpi
|
| 可使用的工具 |
- |
Cutter (blade and blade
holder): Special blade for CAMM-1 series |
| 切割 速度 / 刀壓 / 補正值 |
- |
10 to 600 mm/s (10 to
300 mm/s in the media-feed direction) / 30 to 300 gf / 0.000
to 1.500 mm (0 to 0.0591 in.) |
| 軟體解析度 (切割時) |
- |
0.025 mm/step (0.00984
in./step) |
| 距離精度 (切割時) |
- |
Error of less than± 0.4
% of distance traveled, or 0.3 mm, whichever is greater When
distance correction has been performed (when the setting for
[CALIBRATION] - [CUTTING ADJ.] has been made): Error of less
than± 0.2 % of distance traveled, or 0.1 mm, whichever is
greater
|
| 重複精度 (切割時) |
- |
0.1 mm or less
(excluding stretching/contraction of the media) Range for
assured repetition accuracy For media with a width exceeding
610 mm (24 in.): Length 4000 mm (157-7/16 in.) For media
with a width of 610 mm (24 in.) or less : Length 8000 mm
(315-15/16 in.) |
| 噴切的重複精度 |
- |
±0.5 mm (0.0197 in.)
max. at 25°C (77 °F) (excluding possible shift caused by
expansion/contraction of the media and/or by reloading the
media, and provided that media length is under 3000 mm
(118-1/16 in.)) |
| 傳輸介面 |
Ethernet
10Base-T or 100Base-TX and Bidirectional parallel interface
(compliant with IEEE 1284: Nibble mode, ECP mode (non
compression )) |
| 電源功率 |
列印/切割模式 |
Maximum: 2.0
A/100 V to 240 V ?(10 % 50/60 Hz |
| 待機/切割狀態 |
Maximum: 0.6
A/100 V to 240 V ?(10 % 50/60 Hz |
| 噪音質 |
列印/切割模式 |
65 dB (A) or
less (According to ISO7779) |
| 待機/切割狀態 |
40 dB (A) or
less (According to ISO7779) |
| 機器外觀尺寸 (含腳架) |
3134 mm [W] x 742 mm [D]
x 1300 mm [H] (123-7/16 in. [W] x 29-1/4 in. [D] x 51-3/16
in. [H]) |
2699 mm [W]
x 742 mm [D] x 1300 mm [H]
(106-5/16 in. [W] x 29-1/4 in. [D] x 51-3/16 in. [H] |
| 機器重量 (含腳架) |
173 kg
(381.4 lb.) |
146 kg
(321.8 lb.) |
152 kg (335 lb.) |
| 週邊環境 |
開機 |
溫度: 15 to 32
°C (59 to 89.6 °F), 溼度: 35 to 80 % (non-condensing) |
| 關機 |
溫度: 5 to
40°C (41 to 104 °F), 溼度: 20 to 80 % (non-condensing) |
| 隨機附贈項目 |
Roland
ColorRIP®CD-ROM: 1, Roland-PrintServer CD-ROM: 1, power
cord: 1, drain bottle: 1,replacement blade for separating
knife: 1, cleaning kit: 1, SOL INK cleaning cartridge: 4,
user's manual: 1, Roland PrintServer network settings guide:
1 |
Roland ColorRIP®CD-ROM:
1, Roland-PrintServer CD-ROM: 1, power cord: 1, drain
bottle: 1, blade: 1, blade holder: 1, replacement blade for
separating knife: 1, cleaning kit: 1, SOL INK cleaning
cartridge: 4, user's manual: 1, Roland PrintServer network
settings guide: 1 |
